FBT marks its entry into production of line-arrays with an innovative system offering the latest developments
in true full-range line-array technology. The FBT MODUS Line Array System addresses the problems for
those forced to use traditional constant directivity systems, because of the high cost and difficulty of use of
conventional line array systems. The MODUS solution involves the grouping of 4 modules into a single enclosure
that's no larger than one traditional 2-way speaker enclosure. This design produces vertical and horizontal
dispersion patterns already optimized to effectively meet  a broad range of sound reinforcement requirements,
from small to midsized live touring as well as permanent installations.  The New FBT MODUS Series modules
(Precision Coverage Vertical Array) are very competitive in cost and are extremely easy to use.

No compromise has been made in terms of quality or performance.

The absence of disruptions in the source of the upper-mid frequencies (inevitable in conventional CD
multi-enclosure array applications) and the definition of the vertical angle coverage at the project
development phase, allows for improved evenness and coherence of the wavefront throughout the waveguide,
thereby perfectly modelling a cylindrical wave.

The system is composed of two full range line-array enclosures, the MODUS 15 and MODUS 40 and a
band-pass subwoofer, the MODUS SUB, with all being flyable with the easy to use built-in hardware.  The
two array modules have different shapes in order to cover 90° x 40°  and 90° x 15° dispersion angles, and
can be used either singularly or in tandem to form a J-Array that's able to evenly provide 90° horizontal and
55° vertical angles.  The MODUS SUB subwoofer can be suspended or ground stacked, and provides additional
low-frequency response. Although the maximum performance is obtained when flying the array modules, it is
also possible to ground-stack the MODUS 15 and MODUS 40 with an optional stand base, or to place one
MODUS 15  enclosure on top of a MODUS SUB.
    FBT USA, Inc.  P.O. Box 8144  Berlin, CT. 06037 U.S.A.       Phone  860 829 0434        Fax 860 829 1026      Email: fbtusa@sbcglobal.net
    FBT Electronica SpA       Zona Industriale Squartabue         Recanati, Italy  62019
About Our Company
New !   Amico 900
900w RMS Portable
Sound System
FBT PSR Series Speakers, Monitors & FBT QUBE SERIES QSA 210A Line Arrays
& QUBE RUT Subwoofers   -In a stadium setting
New ! FBT Hi MaxX 40a
650 w RMS, 39.5 lbs.
Not Just Your ORDINARY 2 way Powered Plastic Speakers!
Meet the New FBT Hi Maxx 40a, 650 watts RMS of butt kickin' power and 127 dB SPL, 12 " woofer, 1.7" HF Driver.
Need more power? Check out the
Maxx 6a, 900 watts RMS and 129.5 dB SPL, 15" woofer, 2.5" HF Driver. 64 lbs.
An International Favorite : The FBT Maxx 4a, 400 watts RMS , 123 dB SPL, 12" woofer , 1.4" HF Driver. 35 lbs.
All FBT branded products are Completely "Manufactured in Italy"
FBT Maxx 6a
900 w RMS, 64 lbs.
FBT Maxx 4a
400 w RMS, 35 lbs.
